Applicable materials
|
spunlace non-woven fabric, hot rolled non-woven fabric, dust-free paper
|
|
Raw material weight
|
40-80g/m2
|
|
Folding method
|
"Z", "W", "C"(can be continuously extracted, can be extracted independently)
|
|
Production capacity
|
2000-4000 (sheets / min) (10-60 packs)
|
|
Production range
|
10-120 pumping/bag, product height within 80mm
|
|
Raw material size
|
maximum winding diameter φ1200mm, width 600-1500mm, paper core φ76.2mm
|
|
Folding size
|
length 100-250mm, width 90-110mm (can be customized according to customer requirements)
|
|
Expanded size
|
length 100-250mm, width 90-250mm (can be customized according to customer requirements)
|
|
Stacking method
|
electronic counting, variable number stacking system
|
|
Unwinding mechanism
|
2 sets of unwinding frame, automatic tension control system, synchronous conveying
|
|
Split mechanism
|
2 sets of parent rolls for 12 rows, or 12 independent paper holders
|
|
Opening mechanism
|
synchronous positioning and rotary cutting
|
|
Label system
|
synchronous paste open label
|
|
Humidification mixing system
|
two mixing tanks
|
|
Machine power
|
three-phase AC380V 50/60Hz 15KW
|
|
Machine size
|
20000mm×2000mm×2000mm
|
|
Machine weight
|
12000kg
|
|
Optional accessories
|
Full servo motor
|
Our company was established in 1996, with a total area of 20,000 square meters, with a total staff of 180 people and an annual output of more than 4,000 units.
