Scope of application
Applicable to all kinds of large solids. Blocks, bulk materials, long strips and other materials packaging, river powder, noodles, ham, quick-frozen taro, dumplings and other packaging are widely used in food-pharmaceutical-hardware-daily industries, etc. Complete the whole process of feeding - bag making - sealing - printing batch number - finished product output - counting, etc. Optional 260.350.600 different specifications!
Product advantages
It adopts original single servo or double servo motor control, which is more intelligent than other similar inverter motors or inverter controlled products at home and abroad, with higher packaging precision, wider adjustable range, more precise control and lower scrap rate. Better stability. Thanks to the world's leading fully open box structure, the transmission structure is clear at a glance, and maintenance is more convenient;
|
1、 |
Touch mode man-machine interface control, parameter setting is convenient and fast, high speed and high efficiency. |
|
2、 |
Adopt photoelectric tracking technology, digital input, accurate sealing and cutting position. |
|
3、 |
The fault is diagnosed by itself and the alarm is displayed. |
|
4、 |
Constant temperature adjustment, intelligent control, can adapt to a variety of packaging materials. |
|
5、 |
Double frequency conversion control, the bag length is set to cut, one step in place, saving labor and film. |
| Model |
KD-450 |
| Packaging film width |
Max.450mm |
| Bag width |
50-200mm |
| Bag length |
65-330mm |
| The highest height of the product is |
Max.80mm |
| Film diameter |
Max.350mm |
| Packing speed |
40-250bag/min |
| Machine size |
4000x900x1500mm |
| Machine weight |
680kg |
