Scope of application
It is suitable for packaging large-scale bulk materials with regular solids, such as tray biscuits, no trays, knife-cut steamed buns, bread, quick-frozen food (bulk knife, steamed buns, dumplings, dumplings), and automatic packaging for daily necessities and industrial parts. For irregularly dispersed materials, the packaged material should be placed in a box to form a regular whole before packaging. Widely used in food and pharmaceutical, hardware and other industries!
Product advantages
It adopts original single servo or double servo motor control, which is more intelligent than other similar inverter motors or inverter controlled products at home and abroad, with higher packaging precision, wider adjustable range, more precise control and lower scrap rate. Better stability. Thanks to the world's leading fully open box structure, the transmission structure is clear at a glance, and maintenance is more convenient;
|
1、 |
Touch mode man-machine interface control, parameter setting is convenient and fast, high speed and high efficiency. |
|
2、 |
Adopt photoelectric tracking technology, digital input, accurate sealing and cutting position. |
|
3、 |
The fault is diagnosed by itself and the alarm is displayed. |
|
4、 |
Constant temperature adjustment, intelligent control, can adapt to a variety of packaging materials. |
|
5、 |
Double frequency conversion control, the bag length can be set and cut, one step in place, saving labor and film. |
| Model |
KD-600A |
KD-800A |
| Packaging film width |
Max.580mm |
Max.780mm |
| Bag width |
40-280mm |
80-380mm |
| Packing height |
20-120mm |
20-120mm |
| Film diameter |
Max 320mm |
Max.320mm |
| Packing speed |
20-150bag/min |
20-120bag/min |
| Machine size |
4000x1500x1700mm |
4000x1600x1700mm |
| Machine weight |
900kg |
1000kg |
