KD-260A
Anti-film automatic packaging machine
  • description>
  • performance>
  • parameter>
  • Online inquiry>
product description



Scope of application

Applicable to multi-blocks. Viscosity. Flexible packaging such as (betel nut, candied dates, hawthorn, sticky fruit, etc.) and other irregular materials such as solid bulk electronic components.

Widely used in food-pharmaceutical-hardware-daily and other industries, it can automatically complete the whole process of feeding-bag-sealing-printing batch number-finished output-counting! Optional anti-film KD-350.450. Different models! Various large size materials!


Product advantages

It adopts original single servo or double servo motor control, which is more intelligent than other similar inverter motors or inverter controlled products at home and abroad, with higher packaging precision, wider adjustable range, more precise control and lower scrap rate. Better stability. Thanks to the world's leading fully open box structure, the transmission structure is clear at a glance, and maintenance is more convenient;


Technical performance

1、

Compact structure, stable performance and easy operation.

2、

Double frequency conversion control, the bag length can be set and cut, no need to adjust the empty walk, one step in place, saving time and film.

3、

Adopt imported electrical appliances, touch human-machine interface, parameter setting is convenient and quick, fault self-diagnosis function, fault display is clear at a glance.

4、

The high-sensitivity photoelectric eye color tracking makes the sealing and cutting position more accurate.

5、

Temperature independent PID control, better suited to various material envelopes.

6、

Positioning stop function, no sticking knife, no film.

7、

The rotating system is simple, the work is more reliable, and the maintenance is more convenient.

8、

All control is implemented by software, which is convenient for function adjustment and technical upgrade, and never lags behind.

parameter
Large film width

260mm

Maximum packaging capacity (depending on the material)

50-250 times / min

Suitable for film thickness

0.03-0.06mm

Bag length

60-330mm

Package width

25-110mm

Packing height

≤50mm

Total power

2.2Kw 220V

Machine dimensions (length x width x height)

4000 x 900 x 1500mm

Total weight

500kg
