HY320G/420G/520G
Automatic back sealing granule packing machine
  • description>
  • performance>
  • parameter>
  • Online inquiry>
product description

This unit



1. HY main machine packaging machine can be selected according to product weight (320 420 520 type)

2 measuring cup measuring device

3. Material hoist (optional)

4. Finished conveyor (optional)



Scope of application



Puffed, shrimp, rice, melon seeds, seeds, peanuts and other bulk granules, block, short strip, spherical material



Other functions



This machine can be matched with automatic weighing machine, measuring cup measuring machine, manual feeding conveyor and spiral measuring machine. It has a wide packaging range and is suitable for packaging all kinds of granular, block, strip and powder objects. Granules such as: sugar, salt, monosodium glutamate, seasonings, rice, peanuts, puffed food, coffee, desiccant, washing powder, mung beans, soybeans, melon seeds, potato chips, etc.; powders such as: Chinese medicine powder, medicine powder, veterinary powder , flour, milk powder, pepper, mask powder, starch, pearl powder, etc.; liquids such as: milk, soy milk, edible oil, juice, water, pesticides and other high-dose packaging.



Technical performance

1、

Complete the whole process of feeding, metering, filling and bag making, printing date, inflation (exhaust) and finished product delivery;

2、

the supporting device is convenient and economic;

3、

can be converted into opening and closing door type metering device according to material requirements;

4、

Imported PLC full computer control system, man-machine interface, touch screen operation is simple and intuitive;

5、

Servo film transport system, accurate positioning, excellent machine performance, beautiful packaging;

6、

Perfect automatic alarm protection function to minimize losses;

7、

This machine and the metering device can automatically complete the whole packaging process of metering, feeding, filling and bag making, date printing;

8、

Bag making form: This machine can be made into pillow-shaped bag, vertical bag and hanging hole according to customer needs.

parameter
Model

HY320

Maximum packaging speed

up to 65 bags / minute

Bag length

50-230mm Width: 50-150mm

Film width range

120-320mm

Film thickness

0.04-0.09mm

Power supply

1N+PE/50HZ/AC220V/2KW

Air consumption

0.8Mpa 0.25m3/min

Dimensions

1200x wide 905 x high 1300mm

Machine weight

300kg
